| Broj dijela | LP171WX2-TLB1 |
| Marka | LG Display |
| Veličina | 17.1 |
| Primjena | NBPC |
| Rezolucija | 1440×900 |
| Sastav | LCM |
| Svjetlina | 220 |
| CR | 300:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | LG.Philips LCD |
| panelni model | LP171WX2-TLB1 2 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 17.1 inch |
| rezolucija | 1440(RGB)×900 , WXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 367.2×229.5 mm |
| obris | 382.2×267.2×6.6 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Antiglare, Hard coating (4H) |
| svjetlina | 220 cd/m² (Typ.) |
| omjer kontrasta | 300:1 (Min.) |
| boje prikaza | 262K (6-bit), CIE193145% |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| LP171WP4-TLB1 | LG Display | 17.1 | 1440×900 |
| LP171WP4-TLB4 | LG Display | 17.1 | 1440×900 |
| LP171WP4-TLP1 | LG Display | 17.1 | 1440×900 |
| LP171WU1-TLA2 | LG Display | 17.1 | 1920×1200 |
| LP171WU1-TLA3 | LG Display | 17.1 | 1920×1200 |
| LP171WU5-TLB1 | LG Display | 17.1 | 1920×1200 |
| LP171WU6-TLA1 | LG Display | 17.1 | 1920×1200 |
| LP171WU6-TLB1 | LG Display | 17.1 | 1920×1200 |
| LP171WX2-A4K7 | LG Display | 17.1 | 1440×900 |
| LP171WX2-TLA2 | LG Display | 17.1 | 1440×900 |
| LP140WF1-SPK1 | LG Display | 14.0 | 1920×1080 |
| LP154WE2-TLA8 | LG Display | 15.4 | 1680×1050 |
| LP156WH3-TLC1 | LG Display | 15.6 | 1366×768 |
| LP171WP4-TLQ2 | LG Display | 17.1 | 1440×900 |
| LQ150X1LAM3 | SHARP | 15.0 | 1024×768 |
| LTN133AT16-S01 | Samsung | 13.3 | 1280×800 |
| LTN140AT07-306 | Samsung | 14.0 | 1366×768 |
| LTN156AT05-J08 | Samsung | 15.6 | 1366×768 |
| LTN156AT19-W01 | Samsung | 15.6 | 1366×768 |
| QD15XL06 Rev.01 | QDI | 15.0 | 1024×768 |
