| Broj dijela | LMG9980ZWCC-01 |
| Marka | KOE |
| Veličina | 12.1 |
| Primjena | IA |
| Rezolucija | 800×600 |
| Sastav | LCM |
| Svjetlina | 70 |
| CR | 30:1 |
| Boje | Color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Parallel Data |
| marka panela | HITACHI |
| panelni model | LMG9980ZWCC-01 |
| vrsta panela | CSTN-LCD , LCM |
| veličina ploče | 12.1 inch |
| rezolucija | 800(RGB)×600 , SVGA |
| način prikaza | STN, Normally Black |
| aktivno područje | 246×184.5 mm |
| obris | 275×202.5 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 70 cd/m² (Typ.) |
| omjer kontrasta | 30 : 1 (Typ.) |
| boje prikaza | Color |
| vrijeme odziva | 170/130 (Typ.)(Tr/Td) |
| kut gledanja | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| frekvencija | 120Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | Parallel Data (8-bit), 41 pins |
| ulazni napon | 3.3/5.0V (Typ.)(VDD) |
| primjena | IA |
