| Broj dijela | LM050QC1T01 |
| Marka | SHARP |
| Veličina | 5.0 |
| Primjena | IA |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 100 |
| CR | 30:1 |
| Boje | Color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Parallel Data |
| marka panela | SHARP |
| panelni model | LM050QC1T01 |
| vrsta panela | CSTN-LCD , LCM |
| veličina ploče | 5.0 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | STN, Normally Black, Transmissive |
| aktivno područje | 100.8×75.6 mm |
| obris | 134×100 mm |
| površinski | |
| svjetlina | 100 cd/m² (Typ.) |
| omjer kontrasta | 30:1 (Typ.) |
| boje prikaza | Color |
| vrijeme odziva | 230/120 (Typ.)(Tr/Td) |
| kut gledanja | 35/35/15/25 (Typ.)(CR≥5)(L/R/U/D) |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | Parallel Data (8-bit), 20 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
