| Broj dijela | LD470DXS-SCA1 |
| Marka | LG Display |
| Veličina | 47 |
| Primjena | DID |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 800 |
| CR | 1400:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | LG Display |
| panelni model | LD470DXS-SCA1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 47 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | S-IPS, Normally Black, Transmissive |
| aktivno područje | 1039.87×584.64 mm |
| obris | 1046.8×591.6×50.5 mm, Videowall Seam 6.9 mm |
| površinski | Hard coating (3H), Reflection 2.0% (Max.) |
| svjetlina | 800 cd/m² (Typ.) |
| omjer kontrasta | 1400:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193172% |
| vrijeme odziva | 12 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 8-bit), 30 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | DID |
