| Broj dijela | ASI545FB01-0 |
| Marka | Samsung |
| Veličina | 55 |
| Primjena | DID |
| Rezolucija | 1920×1080 |
| Sastav | OLED |
| Svjetlina | 500 |
| CR | |
| Boje | 1.07B |
| Pozadinsko osvjetljenje | self |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | ASI545FB01-0 |
| vrsta panela | TOLED , OLED |
| veličina ploče | 55 inch |
| rezolucija | 1920×1080(RGB) , FHD |
| aktivno područje | 1209.6×680.4 mm |
| obris | 1219.4×697 mm, Videowall Seam 9.8 mm |
| površinski | Hard coating (2H), Antireflection |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | |
| boje prikaza | 1.07B (10-bit), CIE1931100% |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | LVDS (2 ch, 10-bit), 51 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | DID |
| ASI545FB01-0 | Samsung | 55 | 1920×1080 |
| HV550WUP-200 | BOE | 55 | 1920×1080 |
| LC550EUB-SCA1 | LG Display | 55 | 1920×1080 |
| LC550EUD-SCA1 | LG Display | 55 | 1920×1080 |
| LC550EUG-PEF1 | LG Display | 55 | 1920×1080 |
| LTA550HJ05 | Samsung | 55 | 1920×1080 |
| LTI550HN03 | Samsung | 55 | 1920×1080 |
| T546HW02 V1 | AUO | 55 | 1920×1080 |
| T550QVD01.0 | AUO | 55 | 3840×2160 |
| V546H1-LS1 | Innolux | 55 | 1920×1080 |
| ASI545FB01-0 | Samsung | 55 | 1920×1080 |
| LD470DXS-SCA1 | LG Display | 47 | 1366×768 |
| LD470DXS-SCB1 | LG Display | 47 | 1366×768 |
| LD550DUN-THB3 | LG Display | 55 | 1920×1080 |
| LTI460HN01 | Samsung | 46 | 1920×1080 |
| LTI460HN07 | Samsung | 46 | 1920×1080 |
| LTI460HN09 | Samsung | 46 | 1920×1080 |
| LTI460HN10 | Samsung | 46 | 1920×1080 |
| LTI460HN11 | Samsung | 46 | 1920×1080 |
| LTI550HN14 | Samsung | 55 | 1920×1080 |
