| Broj dijela | LB084S01-TL01 |
| Marka | LG Display |
| Veličina | 8.4 |
| Primjena | IA |
| Rezolucija | 800×600 |
| Sastav | LCM |
| Svjetlina | 600 |
| CR | 600:1 |
| Boje | 262K/16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | LG.Philips LCD |
| panelni model | LB084S01-TL01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.4 inch |
| rezolucija | 800(RGB)×600 , SVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 170.4×127.8 mm |
| obris | 189.5×148.6×9.4 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 600 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193145% |
| vrijeme odziva | 7/18 (Typ.)(Tr/Td) |
| kut gledanja | 75/75/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (1 ch, 6/8-bit), 20 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
