| Broj dijela | KCB6448BSTT-X4 |
| Marka | Kyocera |
| Veličina | 10.4 |
| Primjena | IA |
| Rezolucija | 640×480 |
| Sastav | LCM |
| Svjetlina | |
| CR | 20:1 |
| Boje | Color |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | Parallel Data |
| marka panela | Kyocera |
| panelni model | KCB6448BSTT-X4 |
| vrsta panela | CSTN-LCD , LCM |
| veličina ploče | 10.4 inch |
| rezolucija | 640(RGB)×480 , VGA |
| način prikaza | STN, Normally Black, Transmissive |
| aktivno područje | 211.2×158.4 mm |
| površinski | |
| svjetlina | |
| omjer kontrasta | 20:1 (Typ.) |
| boje prikaza | Color , CIE193140% |
| vrijeme odziva | 160/80 (Typ.)(Tr/Td) |
| kut gledanja | |
| frekvencija | 75Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | Parallel Data (2ch, 8-bit) |
| ulazni napon | 5.0V (Typ.) |
| primjena | IA |
