| Broj dijela | IAQX10M |
| Marka | IDTech |
| Veličina | 15.0 |
| Primjena | DMPC |
| Rezolucija | 2048×1536 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 400:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | IDTech |
| panelni model | IAQX10M |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.0 inch |
| rezolucija | 2048(RGB)×1536 , QXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 304.1×228.1 mm |
| obris | 326×244.5×13.3 mm |
| površinski | |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 30/30 (Typ.)(Tr/Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | DMPC |
