| Broj dijela | HV550WU2-370 |
| Marka | BOE |
| Veličina | 55 |
| Primjena | LCTV |
| Rezolucija | 1920×1080 |
| Sastav | CELL |
| Svjetlina | 0 |
| CR | 1200:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | LVDS |
| marka panela | BOE |
| panelni model | HV550WU2-370 |
| vrsta panela | a-Si TFT-LCD , CELL |
| veličina ploče | 55 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | ADS, Normally Black, Transmissive |
| aktivno područje | 1209.6×680.4 mm |
| obris | 1224.8×699.3 mm |
| površinski | Antiglare (Haze 1%), Hard coating (2H) |
| dubina stakla | 0.70+0.70 mm |
| transmisivnost | 6.3% (Typ.)(with Polarizer) |
| omjer kontrasta | 1200:1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 8 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | LVDS (2 ch, 8-bit), 51 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
| ASI545FB01-0 | Samsung | 55 | 1920×1080 |
| HV550WU2-370 | BOE | 55 | 1920×1080 |
| HV550WUP-200 | BOE | 55 | 1920×1080 |
| LC550EQD-FGF4 | LG Display | 55 | 3840×2160 |
| LC550EUF-FGF1 | LG Display | 55 | 1920×1080 |
| LC550EUH-KEF1 | LG Display | 55 | 1920×1080 |
| LD550DUS-SEF1 | LG Display | 55 | 1920×1080 |
| LD550EUD-SDA1 | LG Display | 55 | 1920×1080 |
| LTA550FW01 | Samsung | 55 | 1920×1080 |
| LTI550HN09 | Samsung | 55 | 1920×1080 |
| LC320EUD-SCA1 | LG Display | 31.5 | 1920×1080 |
| LC420EUG-PEF2 | LG Display | 42 | 1920×1080 |
| LC420EUN-SFM1 | LG Display | 42 | 1920×1080 |
| LC430EGG-FHM1 | LG Display | 43 | 3840×2160 |
| LC470WU1-SLA1 | LG Display | 47 | 1920×1080 |
| LTY460HH-LH2 | Samsung | 46 | 1920×1080 |
| ST2751A01-4 | CSOT | 27.5 | 1366×768 |
| T645HF02 V1 | AUO | 65 | 1920×1080 |
| V236BJ1-PE2 | Innolux | 23.6 | 1366×768 |
| V315B6-L04 | Innolux | 31.5 | 1366×768 |
