| Broj dijela | HV121X02-100 |
| Marka | HYDIS |
| Veličina | 12.1 |
| Primjena | IA |
| Rezolucija | 1024×768 |
| Sastav | CELL |
| Svjetlina | 0 |
| CR | 450:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | LVDS |
| marka panela | BOE HYDIS |
| panelni model | HV121X02-100 |
| vrsta panela | a-Si TFT-LCD , CELL |
| veličina ploče | 12.1 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | AFFS, Normally Black, Transmissive |
| aktivno područje | 245.76×184.32 mm |
| površinski | Glare (Haze 0%), Antireflection |
| transmisivnost | 5.91% (Typ.)(with Polarizer) |
| omjer kontrasta | 450:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193140% |
| vrijeme odziva | 32 (Typ.)(Tr+Td) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | LVDS (1 ch, 6-bit), 20 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
