| Broj dijela | HT150X02-100 |
| Marka | BOE |
| Veličina | 15.0 |
| Primjena | IA |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 500:1 |
| Boje | 16.2M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | BOE |
| panelni model | HT150X02-100 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.0 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 304.128×228.096 mm |
| obris | 326.5×253.5×11.9 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 16.2M (6-bit + FRC), CIE193160% |
| vrijeme odziva | 2/6 (Typ.)(Tr/Td) |
| kut gledanja | 75/75/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 20 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
