| Broj dijela | HSD170MGW1-B01 |
| Marka | HannStar |
| Veličina | 17.0 |
| Primjena | DMPC |
| Rezolucija | 1440×900 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 600:1 |
| Boje | 16.2M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | HannStar |
| panelni model | HSD170MGW1-B01 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 17.0 inch |
| rezolucija | 1440(RGB)×900 , WXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 367.2×229.5 mm |
| obris | 389.2×254.5×11.8 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 16.2M (6-bit + FRC), CIE193163% |
| vrijeme odziva | 3/5 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/65/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
