| Broj dijela | EK08009-70235 |
| Marka | Other |
| Veličina | 8.0 |
| Primjena | DPF |
| Rezolucija | 800×600 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 500:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | No Brand |
| panelni model | EK08009-70235 4 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.0 inch |
| rezolucija | 800(RGB)×600 , SVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 162×121.5 mm |
| obris | 183×141 mm |
| površinski | Antiglare |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193150% |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 3S11PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit), 50 pins |
| ulazni napon | 3.3/10.4V (Typ.)(VCC/AVDD) |
| rohs: | |
| primjena | DPF |
