| Broj dijela | HSD090ICW1-A00 |
| Marka | HannStar |
| Veličina | 9.0 |
| Primjena | DPF |
| Rezolucija | 640×234 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 500:1 |
| Boje | |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | Analog |
| marka panela | HannStar |
| panelni model | HSD090ICW1-A00 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 9.0 inch |
| rezolucija | 640(RGB)×234 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 197.76×111.735 mm |
| obris | 210.7×126.4×4.25 mm |
| površinski | |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | , CIE193145% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| tip svjetiljke | 3S8PWLEDWithout Driver |
| signalno sučelje | TFT Specific Analog RGB, 26 pins |
| ulazni napon | 3.3/5/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL) |
| primjena | DPF |
