| Broj dijela | COM57H5M10XRC |
| Marka | ORTUSTECH |
| Veličina | 5.7 |
| Primjena | IA |
| Rezolucija | 640×480 |
| Sastav | LCM |
| Svjetlina | 360 |
| CR | 400:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | ORTUSTECH |
| panelni model | COM57H5M10XRC |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.7 inch |
| rezolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transflective |
| aktivno područje | 115.2×86.4 mm |
| obris | 130.32×101.2 mm |
| površinski | |
| svjetlina | 360 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.)(Transmissive)2:1 (Typ.)(Reflective) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 40/60 (Max.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | Parallel RGB (1 ch, 6-bit) |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
