| Broj dijela | C070VW04 V7 |
| Marka | AUO |
| Veličina | 7.0 |
| Primjena | CNS |
| Rezolucija | 800×480 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 1500:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | AUO |
| panelni model | C070VW04 V7 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 7.0 inch |
| rezolucija | 800(RGB)×480 , WVGA |
| način prikaza | AMVA, Normally Black, Transmissive |
| aktivno područje | 152.4×91.44 mm |
| obris | 164.55×105.01×12.05 mm |
| površinski | Antiglare |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 1500:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 10/25 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4S3PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit), 50 pins |
| ulazni napon | 3.3/12.5/15.0/-9.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| primjena | CNS |
