| Broj dijela | BT140GW01 V.0 |
| Marka | Innolux |
| Veličina | 14.0 |
| Primjena | NBPC |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 220 |
| CR | 600:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | INNOLUX |
| panelni model | BT140GW01 V.0 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 14.0 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 309.399×173.952 mm |
| obris | 323.5×192×5.2 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Glare (Haze 0%), Hard coating (3H) |
| svjetlina | 220 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193160% |
| vrijeme odziva | 8 (Typ.)(Tr+Td) |
| kut gledanja | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| BT140GW01 V.0 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.4 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.5 | Innolux | 14.0 | 1366×768 |
| BT140GW01 V.A | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.0 | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.2 | Innolux | 14.0 | 1366×768 |
| BT140GW02 V.9 | Innolux | 14.0 | 1366×768 |
| BT140GW03 V.2 | Innolux | 14.0 | 1366×768 |
| LTN140KT03 | Samsung | 14.0 | 1600×900 |
| N140BGE-L23 | Innolux | 14.0 | 1366×768 |
| B101EW01 V1 | AUO | 10.1 | 1280×720 |
| B101EW02 V0 | AUO | 10.1 | 1280×720 |
| LP125WH2-TLFA | LG Display | 12.5 | 1366×768 |
| LP156WF4-SPC1 | LG Display | 15.6 | 1920×1080 |
| LTN121XJ-L05 | Samsung | 12.1 | 1024×768 |
| LTN133AT17-104 | Samsung | 13.3 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| M140NWR2 R0 | IVO | 14.0 | 1366×768 |
| N133BGE-L21 | Innolux | 13.3 | 1366×768 |
| N141C1-L01 | Innolux | 14.1 | 1440×900 |
