| Broj dijela | B140QAN01.1 |
| Marka | AUO |
| Veličina | 14.0 |
| Primjena | NBPC |
| Rezolucija | 2560×1440 |
| Sastav | LCM |
| Svjetlina | 340 |
| CR | 700:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | eDP |
| marka panela | AUO |
| panelni model | B140QAN01.1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 14.0 inch |
| rezolucija | 2560(RGB)×1440 , Quad-HD |
| način prikaza | AHVA, Normally Black, Transmissive |
| aktivno područje | 309.35×174.01 mm |
| obris | 320.4×205.1×2.6 mm |
| stil oblika | Slim (PCBA Flat, Depth ≤3.2mm) |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 340 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193172% |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | eDP (4 Lanes), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
