| Broj dijela | B101XAN01.3 |
| Marka | AUO |
| Veličina | 10.1 |
| Primjena | PAD |
| Rezolucija | 1366×768 |
| Sastav | CELL |
| Svjetlina | 0 |
| CR | 900:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | No B/L |
| Sučelje | LVDS |
| marka panela | AUO |
| panelni model | B101XAN01.3 |
| vrsta panela | a-Si TFT-LCD , CELL |
| veličina ploče | 10.1 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | AHVA, Normally Black, Transmissive |
| aktivno područje | 222.52×125.11 mm |
| obris | 230.62×135.81×0.805 mm |
| površinski | Hard coating, Antireflection |
| dubina stakla | 0.25+0.25 mm |
| omjer kontrasta | 900:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193150% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| signalno sučelje | LVDS (1 ch, 8-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
