| Broj dijela | YXD101301000-60 |
| Marka | SEBO |
| Veličina | 10.1 |
| Primjena | CNS |
| Rezolucija | 1024×600 |
| Sastav | LCM |
| Svjetlina | 1000 |
| CR | 600:1 |
| Boje | 16.2M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SEBO |
| panelni model | YXD101301000-60 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.1 inch |
| rezolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 222.72×125.28 mm |
| obris | 235×149.2×6.3 mm |
| površinski | Antiglare |
| svjetlina | 1000 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 16.2M (6-bit + FRC), CIE193152% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 60 pins |
| ulazni napon | 3.3/9.6/18/-6V (Typ.)(DVDD/AVDD/VGH/VGL) |
| primjena | CNS |
