| Broj dijela | ACX425AKM |
| Marka | SONY |
| Veličina | 3.7 |
| Primjena | MPH |
| Rezolucija | 480×800 |
| Sastav | LCM |
| Svjetlina | 320 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SONY |
| panelni model | ACX425AKM |
| vrsta panela | LTPS TFT-LCD , LCM |
| veličina ploče | 3.7 inch |
| rezolucija | 480(RGB)×800 , WVGA |
| način prikaza | Normally Black, Transmissive |
| aktivno područje | 48.24×80.4 mm |
| obris | 53.9×90 mm |
| površinski | Hard coating (3H) |
| svjetlina | 320 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193190% |
| vrijeme odziva | 35 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 7S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6-bit) + SPI, 40 pins |
| ulazni napon | 2.6/2.6V (Typ.)(VDD/AVDD) |
| primjena | MPH |
