| Broj dijela | A101AIE40L0 |
| Marka | Aptus |
| Veličina | 10.1 |
| Primjena | IA |
| Rezolucija | 1280×720 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | Aptus |
| panelni model | A101AIE40L0 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.1 inch |
| rezolucija | 1280(RGB)×720 , WXGA |
| način prikaza | AHVA, Normally Black, Transmissive |
| aktivno područje | 223.68×125.82 mm |
| obris | 238.6×148 mm |
| površinski | |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC) |
| vrijeme odziva | 40 (Max.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 9S3PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 40 pins |
| ulazni napon | 3.3/3.3V (Typ.)(VDD/AVDD) |
| primjena | IA |
| A101AIE40L0 | Aptus | 10.1 | 1280×720 |
| A101VW01 V3 | AUO | 10.1 | 800×480 |
| B101AW01 V2 HW0A | AUO | 10.1 | 1024×576 |
| B101EVT05.0 | AUO | 10.1 | 1280×800 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| LP101WH1-TLB2 | LG Display | 10.1 | 1366×768 |
| LP101WSB-TLN1 | LG Display | 10.1 | 1024×600 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| PQ 3Qi-01 | Pixel Qi | 10.1 | 1024×600 |
| AA090MC01 | Mitsubishi | 9.0 | 800×480 |
| G084SN05 V5 | AUO | 8.4 | 800×600 |
| G104S1-L01 | Innolux | 10.4 | 800×600 |
| LB104S01-TL02 | LG Display | 10.4 | 800×600 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| M150MNN1 R1 | IVO | 15.0 | 1024×768 |
| NL10276BC30-18 | NLT | 15.0 | 1024×768 |
| PD057VT3 | E Ink | 5.7 | 640×480 |
| TM057KDH02 | Tianma | 5.7 | 320×240 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
