| Broj dijela | V500DK1-KS5 |
| Marka | Innolux |
| Veličina | 50 |
| Primjena | LCTV |
| Rezolucija | 3840×2160 |
| Sastav | LCM |
| Svjetlina | 550 |
| CR | 4800:1 |
| Boje | 1.07B |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | V-by-One |
| marka panela | CHIMEI INNOLUX |
| panelni model | V500DK1-KS5 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 50 inch |
| rezolucija | 3840(RGB)×2160 , UHD |
| način prikaza | Super MVA, Normally Black, Transmissive |
| aktivno područje | 1095.84×616.41 mm |
| obris | 1115×638.4×28.6 mm |
| površinski | Antiglare (Haze 1%), Hard coating (3H) |
| svjetlina | 550 cd/m² (Typ.) |
| omjer kontrasta | 4800:1 (Typ.) |
| boje prikaza | 1.07B (8-bit + Hi-FRC), CIE193188% |
| vrijeme odziva | 6.5 (Typ.)(G to G) |
| kut gledanja | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvencija | 120Hz |
| tip svjetiljke | WLEDWithout Driver |
| signalno sučelje | V-by-One 16 lane, 92 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
