| Broj dijela | UG-2832KLBEG04 |
| Marka | WiseChip |
| Veličina | 0.91 |
| Primjena | SB |
| Rezolucija | 128×32 |
| Sastav | OLED |
| Svjetlina | 150 |
| CR | 10000:1 |
| Boje | Mono(Blue) |
| Pozadinsko osvjetljenje | self |
| Sučelje | SPI |
| marka panela | WiseChip |
| panelni model | UG-2832KLBEG04 |
| vrsta panela | PM-OLED , OLED |
| veličina ploče | 0.91 inch |
| rezolucija | 128×32 |
| aktivno područje | 22.384×5.584 mm |
| obris | 31.66×11.5×1.55 mm |
| površinski | Antiglare |
| svjetlina | 150 cd/m² (Typ.) |
| omjer kontrasta | 10000 : 1 (Typ.) |
| boje prikaza | Mono(Blue) |
| kut gledanja | |
| vozač ic | COG Built-in SSD1306 |
| signalno sučelje | 4-wire SPI, 15 pins |
| ulazni napon | 2.8/7.5V (Typ.)(VDD/VCC) |
| primjena | SB |
| OEL9M0068-Y-E | Other | 0.91 | 128×32 |
| OEL9M0084-B-E | Other | 0.91 | 128×32 |
| OEL9M0084-W-E | Other | 0.91 | 128×32 |
| OEL9M0084-Y-E | Other | 0.91 | 128×32 |
| UG-2832HLBEG04 | WiseChip | 0.91 | 128×32 |
| UG-2832HSWEG04 | WiseChip | 0.91 | 128×32 |
| UG-2832KLBEG04 | WiseChip | 0.91 | 128×32 |
| UG-2832TLBGG01 | WiseChip | 1.0 | 128×32 |
| UG-2832TSWGG01 | WiseChip | 1.0 | 128×32 |
| EPW1802AA | Futaba | 1.8 | 160×32 |
| ES063TC1 | E Ink | 6.3 | 200×1040 |
| NVK16BSC001G-C-0000 | Neoview Kolon | 1.7 | 80×168 |
| OEL9M0068-G-E | Other | 0.91 | 128×32 |
| OEL9M0068-R-E | Other | 0.91 | 128×32 |
| OEL9M0068-W-E | Other | 0.91 | 128×32 |
| OEL9M0068-Y-E | Other | 0.91 | 128×32 |
| RGC05072032WR000 | RiTdisplay | 0.48 | 72×32 |
| UG-2832HSWEG04 | WiseChip | 0.91 | 128×32 |
| UG-2832KLBEG04 | WiseChip | 0.91 | 128×32 |
