| Broj dijela | TX39D80VC1GAA |
| Marka | KOE |
| Veličina | 15.4 |
| Primjena | NBPC |
| Rezolucija | 1280×800 |
| Sastav | LCM |
| Svjetlina | 480 |
| CR | 600:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | HITACHI |
| panelni model | TX39D80VC1GAA |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.4 inch |
| rezolucija | 1280(RGB)×800 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 331.2×207 mm |
| obris | 344×225 mm |
| površinski | Glare (Haze 0%) |
| svjetlina | 480 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Min.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 50 (Typ.)(Tr+Td) |
| kut gledanja | |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (1 ch, 6-bit) |
| ulazni napon | 3.3V (Typ.) |
| rohs: | |
| primjena | NBPC |
