| Broj dijela | TV101QUM-N00 |
| Marka | BOE |
| Veličina | 10.1 |
| Primjena | PAD |
| Rezolucija | 3840×2160 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 1500:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | eDP |
| marka panela | BOE |
| panelni model | TV101QUM-N00 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.1 inch |
| rezolucija | 3840(RGB)×2160 , UHD |
| način prikaza | ADS, Normally Black, Transmissive |
| aktivno područje | 222.912×125.388 mm |
| obris | 231.6×140.9 mm |
| površinski | |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 1500:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE1931100% |
| vrijeme odziva | 30 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 8S6PWLEDWithout Driver |
| signalno sučelje | eDP (4 Lanes), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | PAD |
