| Broj dijela | TM123XDHP90 |
| Marka | TIANMA |
| Veličina | 12.3 |
| Primjena | Industrial Outdoor H |
| Rezolucija | 1920×720 |
| Sastav | a-Si TFT-LCD, LCM |
| Svjetlina | |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | 10S4P |
| Sučelje | LVDS |
| marka panela | TIANMA |
| panelni model | TM123XDHP90 |
| veličina ploče | 12.3" |
| vrsta panela | a-Si TFT-LCD, LCM |
| rezolucija | 1920(RGB)×720, 166PPI |
| format piksela | RGB Vertical Stripe |
| područje prikaza | 292.32(W)×109.62(H) mm |
| otvor za okvir | - |
| veličina obrisa | 311(W)×130(H) ×15.7(D) mm |
| površinski | Antiglare (Haze 28%) |
| svjetlina | 1000 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) (TM) |
| kut gledanja | - |
| način prikaza | SFT, Normally Black, Transmissive |
| najbolji pogled na | Symmetry |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| boje prikaza | 16.7M 98% sRGB |
| tip svjetiljke | 10S4P WLED , 10K hours , Without Driver |
| frekvencija | 60Hz |
| ekran na dodir | Without |
| težina panela | 490g (Typ.) |
| primjena | Industrial Outdoor High Brightness Automotive Display |
| signalno sučelje | LVDS (2 ch, 8-bit) , 50 pins FPC |
| ulazni napon | 3.3V (Typ.) |
| okoliš | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
