| Broj dijela | TM104SDH02 |
| Marka | Tianma |
| Veličina | 10.4 |
| Primjena | IA |
| Rezolucija | 800×600 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 500:1 |
| Boje | 262K/16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | TIANMA |
| panelni model | TM104SDH02 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.4 inch |
| rezolucija | 800(RGB)×600 , SVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 211.2×158.4 mm |
| obris | 243×179.4×8.5 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 262K/16.7M (6-bit / 8-bit), CIE193150% |
| vrijeme odziva | 10/15 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 5S8PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 6/8-bit), 20 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
| AA104VC04 | Mitsubishi | 10.4 | 640×480 |
| B104SN01 V0 | AUO | 10.4 | 800×600 |
| NL6448BC33-46 | NLT | 10.4 | 640×480 |
| NL8060BC26-27 | NLT | 10.4 | 800×600 |
| TM104QDSG09 | Tianma | 10.4 | 640×480 |
| TM104SBH01 | Tianma | 10.4 | 800×600 |
| TM104SCH02 | Tianma | 10.4 | 800×600 |
| TM104SDH01 | Tianma | 10.4 | 800×600 |
| TM104SDH02 | Tianma | 10.4 | 800×600 |
| TM104SDHG30 | Tianma | 10.4 | 800×600 |
| AA121SL07 | Mitsubishi | 12.1 | 800×600 |
| AM-320240N1TMQW-T30H-D(R) | AMPIRE | 5.7 | 320×240 |
| DLC1500AMG-1 | Other | 15.0 | 1024×768 |
| G121SN01 V1 | AUO | 12.1 | 800×600 |
| G170EG01 V1 | AUO | 17.0 | 1280×1024 |
| LB121S03-TL01 | LG Display | 12.1 | 800×600 |
| LTD104C11Z | TOSHIBA | 10.4 | 640×480 |
| M101GWN9 R2 | IVO | 10.1 | 1024×600 |
| PM070WX9 | E Ink | 7.0 | 800×480 |
| RGS11096096FR006 | RiTdisplay | 1.1 | 96×96 |
