| Broj dijela | TM084SDHG02 |
| Marka | Tianma |
| Veličina | 8.4 |
| Primjena | IA |
| Rezolucija | 800×600 |
| Sastav | LCM |
| Svjetlina | 330 |
| CR | 500:1 |
| Boje | 262K/16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | TIANMA |
| panelni model | TM084SDHG02 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 8.4 inch |
| rezolucija | 800(RGB)×600 , SVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 170.4×127.8 mm |
| obris | 189.75×149.4 mm |
| površinski | Antiglare |
| svjetlina | 330 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| vrijeme odziva | 20 (Typ.)(Tr+Td) |
| kut gledanja | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 3S7PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 6/8-bit), 60 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | IA |
