| Broj dijela | T420HW08 V5 |
| Marka | AUO |
| Veličina | 42 |
| Primjena | LCTV |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 4000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | AUO |
| panelni model | T420HW08 V5 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 42 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | AMVA3, Normally Black, Transmissive |
| aktivno područje | 930.24×523.26 mm |
| obris | 968.4×564×28.7 mm |
| površinski | Antiglare (Haze 2%), Hard coating (3H) |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 4000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193172% |
| vrijeme odziva | 6.5 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (2 ch, 8-bit), 51 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
| T420HB01 V1 | AUO | 42 | 1920×1080 |
| T420HVN01.1 | AUO | 42 | 1920×1080 |
| T420HVN04.0 CELL | AUO | 42 | 1920×1080 |
| T420HVN04.5 CELL | AUO | 42 | 1920×1080 |
| T420HW04 V3 | AUO | 42 | 1920×1080 |
| T420HW06 V5 | AUO | 42 | 1920×1080 |
| T420HW07 V1 | AUO | 42 | 1920×1080 |
| T420HW07 V4 | AUO | 42 | 1920×1080 |
| T420HW07 V7 | AUO | 42 | 1920×1080 |
| T420HW08 V9 | AUO | 42 | 1920×1080 |
| LC215EXE-SGA1 | LG Display | 21.5 | 1366×768 |
| LC320DXJ-SFE1 | LG Display | 31.5 | 1366×768 |
| LC320DXN-SER2 | LG Display | 31.5 | 1366×768 |
| LC550EQE-PGF1 | LG Display | 55 | 3840×2160 |
| LM320TU4A | PANDA | 31.5 | 1366×768 |
| MT3151A05-2 | CSOT | 31.5 | 1366×768 |
| T260HW01 V0 | AUO | 26.0 | 1920×1080 |
| T420HVN05.2 | AUO | 42 | 1920×1080 |
| V236BJ1-P01 | Innolux | 23.6 | 1366×768 |
| V260H1-LE1 | Innolux | 26.0 | 1920×1080 |
