| Broj dijela | T420HW04 V2 |
| Marka | AUO |
| Veličina | 42 |
| Primjena | LCTV |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 500 |
| CR | 5000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | AUO |
| panelni model | T420HW04 V2 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 42 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | AMVA3, Normally Black, Transmissive |
| aktivno područje | 930.24×523.26 mm |
| obris | 983×576 mm |
| površinski | Antiglare (Haze 11%), Hard coating (3H) |
| svjetlina | 500 cd/m² (Typ.) |
| omjer kontrasta | 5000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193172% |
| vrijeme odziva | 6.5 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 16 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | LVDS (2 ch, 8-bit), 51 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
| T420HVN01.1 CELL | AUO | 42 | 1920×1080 |
| T420HVN02.1 | AUO | 42 | 1920×1080 |
| T420HVN04.5 CELL | AUO | 42 | 1920×1080 |
| T420HVN05.2 | AUO | 42 | 1920×1080 |
| T420HVN06.1 | AUO | 42 | 1920×1080 |
| T420HW04 V3 | AUO | 42 | 1920×1080 |
| T420HW05 V3 | AUO | 42 | 1920×1080 |
| T420HW07 V1 | AUO | 42 | 1920×1080 |
| T420HW09 V1 | AUO | 42 | 1920×1080 |
| T420HW09 V2 | AUO | 42 | 1920×1080 |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LC320WUN-SCA2 | LG Display | 31.5 | 1920×1080 |
| LC320WUN-SCA3 | LG Display | 31.5 | 1920×1080 |
| LC470EUF-SDA1 | LG Display | 47 | 1920×1080 |
| LTA460HB03 | Samsung | 46 | 1920×1080 |
| LTA550HJ07 | Samsung | 55 | 1920×1080 |
| T546HW02 V1 | AUO | 55 | 1920×1080 |
| V400H1-L10 | Innolux | 40 | 1920×1080 |
| V460H1-LH9 | Innolux | 46 | 1920×1080 |
| V650HP1-ME2 | Innolux | 65 | 1920×1080 |
