| Broj dijela | NL256204AM15-02A |
| Marka | NLT |
| Veličina | 20.1 |
| Primjena | DMPC |
| Rezolucija | 2560×2048 |
| Sastav | LCM |
| Svjetlina | 850 |
| CR | 600:1 |
| Boje | Grayscale |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | NEC |
| panelni model | NL256204AM15-02A |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 20.1 inch |
| rezolucija | 2560(LCR)×2048 , QSXGA |
| način prikaza | SA-SFT, Normally Black, Transmissive |
| aktivno područje | 399.36×319.49 mm |
| obris | 423.4×343.5×45.5 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 850 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | Grayscale (8-bit) |
| vrijeme odziva | 15/15 (Typ.)(Tr/Td) |
| kut gledanja | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 12 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | LVDS (4 ch, 8-bit) |
| ulazni napon | 12.0V (Typ.) |
| rohs: | |
| primjena | DMPC |
