| Broj dijela | N154Z1-L01 |
| Marka | Innolux |
| Veličina | 15.4 |
| Primjena | NBPC |
| Rezolucija | 1680×1050 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 500:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | CMO |
| panelni model | N154Z1-L01 9 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.4 inch |
| rezolucija | 1680(RGB)×1050 , WSXGA+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 331.128×206.955 mm |
| obris | 344×222×6.5 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Antiglare, Hard coating (2H) |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193145% |
| vrijeme odziva | 4/12 (Typ.)(Tr/Td) |
| kut gledanja | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| B154EW02 V1 | AUO | 15.4 | 1280×800 |
| LP154WX4-TLC5 | LG Display | 15.4 | 1280×800 |
| LTN154AT07-H01 | Samsung | 15.4 | 1280×800 |
| LTN154AT07-L01 | Samsung | 15.4 | 1280×800 |
| LTN154P1-L03 | Samsung | 15.4 | 1680×1050 |
| N154C6-L04 | Innolux | 15.4 | 1440×900 |
| N154I6-L03 | Innolux | 15.4 | 1280×800 |
| N154Z1-L01 | Innolux | 15.4 | 1680×1050 |
| N154Z1-L02 | Innolux | 15.4 | 1680×1050 |
| N154Z3-L01 | Innolux | 15.4 | 1680×1050 |
| B141XN04 V2 | AUO | 14.1 | 1024×768 |
| LP125WH2-SLB2 | LG Display | 12.5 | 1366×768 |
| LP140WD1-TLM1 | LG Display | 14.0 | 1600×900 |
| LP140WH2-TLB1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TPS1 | LG Display | 14.0 | 1366×768 |
| LP154WU1-A1K3 | LG Display | 15.4 | 1920×1200 |
| LP171WU6-TLA2 | LG Display | 17.1 | 1920×1200 |
| LTD121EXSS | TOSHIBA | 12.1 | 1280×800 |
| LTN141AT16-003 | Samsung | 14.1 | 1280×800 |
| LTN154X3-L03 | Samsung | 15.4 | 1280×800 |
