| Broj dijela | LTN156AT02 |
| Marka | Samsung |
| Veličina | 15.6 |
| Primjena | NBPC |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 220 |
| CR | 600:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTN156AT02 16 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.6 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 344.232×193.536 mm |
| obris | 359.3×209.5×5.5 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Glare (Haze 0%), Hard coating (3H) |
| svjetlina | 220 cd/m² (Typ.) |
| omjer kontrasta | 600:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193160% |
| vrijeme odziva | 25 (Typ.)(Tr+Td) |
| kut gledanja | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 6-bit), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| LTN150PF-L03 | Samsung | 15.0 | 1400×1050 |
| LTN150XG-L02 | Samsung | 15.0 | 1024×768 |
| LTN154AT09-101 | Samsung | 15.4 | 1280×800 |
| LTN154BT05-001 | Samsung | 15.4 | 1440×900 |
| LTN154BT07-S01 | Samsung | 15.4 | 1440×900 |
| LTN154XB-L01 | Samsung | 15.4 | 1280×800 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT02-A04 | Samsung | 15.6 | 1366×768 |
| LTN156AT02-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT17-D01 | Samsung | 15.6 | 1366×768 |
| B121EW02 V0 | AUO | 12.1 | 1280×800 |
| B156HTN04.0 | AUO | 15.6 | 1920×1080 |
| B170PW06 V2 | AUO | 17.0 | 1440×900 |
| LP133WX2-TLA1 | LG Display | 13.3 | 1280×800 |
| LP133WX2-TLD1 | LG Display | 13.3 | 1280×800 |
| LP140WH4-TLD1 | LG Display | 14.0 | 1366×768 |
| LTN133W1-L01 | Samsung | 13.3 | 1280×800 |
| N140FGE-L32 | Innolux | 14.0 | 1600×900 |
| N154I5-L02 | Innolux | 15.4 | 1280×800 |
| NL8060BC26-13 | NLT | 10.4 | 800×600 |
