| Broj dijela | LTN133YL01-F01 |
| Marka | Samsung |
| Veličina | 13.3 |
| Primjena | NBPC |
| Rezolucija | 3200×1800 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | eDP |
| marka panela | SAMSUNG |
| panelni model | LTN133YL01-F01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 13.3 inch |
| rezolucija | 3200RG(BW)×1800 , Quad-HD+ |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno područje | 293.44×165.06 mm |
| obris | 306.15×188.2 mm |
| stil oblika | Slim (PCBA Flat, Depth ≤3.2mm) |
| površinski | |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 800:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193172% |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 11S5PWLEDEmbedded (LED Driver) |
| signalno sučelje | eDP (4 Lanes), 40 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
