| Broj dijela | LTM200KT03 |
| Marka | Samsung |
| Veličina | 20.0 |
| Primjena | DMPC |
| Rezolucija | 1600×900 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 1000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTM200KT03 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 20.0 inch |
| rezolucija | 1600(RGB)×900 , HD+ |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 442.8×249.075 mm |
| obris | 462.8×272×17.5 mm |
| površinski | Antiglare (Haze 25%), Hard coating (3H) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 1000:1 (Typ.) |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 5 (Typ.)(Tr+Td) |
| kut gledanja | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFLWithout Driver |
| signalno sučelje | LVDS (2 ch, 8-bit), 30 pins |
| ulazni napon | 5.0V (Typ.) |
| primjena | DMPC |
| LTM200KT01 | Samsung | 20.0 | 1600×900 |
| LTM200KT03 | Samsung | 20.0 | 1600×900 |
| LTM200KT05 | Samsung | 20.0 | 1600×900 |
| LTM200KT07 | Samsung | 20.0 | 1600×900 |
| LTM200KT08-V | Samsung | 20.0 | 1600×900 |
| LTM200KT10 | Samsung | 20.0 | 1600×900 |
| LTM200KT12 | Samsung | 20.0 | 1600×900 |
| LTM201M1-L01 | Samsung | 20.1 | 1680×1050 |
| LTM201M2-L02 | Samsung | 20.1 | 1680×1050 |
| LTM201U1-L01 | Samsung | 20.1 | 1600×1200 |
| CLAA185WA02 | CPT | 18.5 | 1366×768 |
| LM185WH1-TLA1 | LG Display | 18.5 | 1366×768 |
| LM220W1-A2MN | LG Display | 22.0 | 1600×1024 |
| LM230WU3-STC3 | LG Display | 23.0 | 1920×1200 |
| LTM200KP01 | Samsung | 20.0 | 1600×900 |
| M200FGE-L20 | Innolux | 20.0 | 1600×900 |
| M215HW03 V1Q0 | AUO | 21.5 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| M270HW02 V0 | AUO | 27.0 | 1920×1080 |
| M300DVR01.1 | AUO | 30.0 | 2560×1080 |
