| Broj dijela | LTI400HA01 |
| Marka | Samsung |
| Veličina | 40 |
| Primjena | PID |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 450 |
| CR | 4000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTI400HA01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 40 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | S-PVA, Normally Black, Transmissive |
| aktivno područje | 885.6×498.15 mm |
| obris | 952×551 mm |
| površinski | Antiglare (Haze 44%), Hard coating (3H) |
| svjetlina | 450 cd/m² (Typ.) |
| omjer kontrasta | 4000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193172% |
| vrijeme odziva | 15/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 14 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | LVDS (2 ch, 8-bit), 51 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | PID |
| LTI400HA01 | Samsung | 40 | 1920×1080 |
| LTI400HA02 | Samsung | 40 | 1920×1080 |
| LTI400HA03 | Samsung | 40 | 1920×1080 |
| LTI400HA04 | Samsung | 40 | 1920×1080 |
| LTI400HA05 | Samsung | 40 | 1920×1080 |
| LTI400HA06 | Samsung | 40 | 1920×1080 |
| LTI400HA08-V | Samsung | 40 | 1920×1080 |
| LTY400HA01 | Samsung | 40 | 1920×1080 |
| T400XW01 V7 | AUO | 40 | 1366×768 |
| V400HJ6-ME2 | Innolux | 40 | 1920×1080 |
| LD470EUD-SDA1 | LG Display | 47 | 1920×1080 |
| LD550WUP-SCA1 | LG Display | 55 | 1920×1080 |
| LK460D3LA8S | SHARP | 46 | 1920×1080 |
| LK695D3LA18 | SHARP | 70 | 1920×1080 |
| LTI290LN01 | Samsung | 29.0 | 1920×540 |
| LTI460HN05 | Samsung | 46 | 1920×1080 |
| LTI520HB01 | Samsung | 52 | 1920×1080 |
| P320HVN02.1 | AUO | 31.5 | 1920×1080 |
| P460HW02 V0 | AUO | 46 | 1920×1080 |
| P550HVN06.0 | AUO | 55 | 1920×1080 |
