| Broj dijela | LTD121EWRF |
| Marka | TOSHIBA |
| Veličina | 12.1 |
| Primjena | NBPC |
| Rezolucija | 1280×800 |
| Sastav | LCM |
| Svjetlina | 300 |
| CR | 250:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | Toshiba Mobile Display |
| panelni model | LTD121EWRF |
| vrsta panela | LTPS TFT-LCD , LCM |
| veličina ploče | 12.1 inch |
| rezolucija | 1280(RGB)×800 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 261.12×163.2 mm |
| obris | 268.1×180.2×4.27 mm |
| površinski | Antiglare |
| svjetlina | 300 cd/m² (Typ.) |
| omjer kontrasta | 250:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 80 (Max.)(Tr+Td) |
| kut gledanja | |
| frekvencija | 60Hz |
| tip svjetiljke | 6 stringsWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 6-bit), 30 pins |
| ulazni napon | 2.5V (Typ.) |
| primjena | NBPC |
