| Broj dijela | LTA320HN02-W |
| Marka | Samsung |
| Veličina | 31.5 |
| Primjena | LCTV |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 430 |
| CR | 5000:1 |
| Boje | 1.07B |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTA320HN02-W |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 31.5 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | SVA, Normally Black, Transmissive |
| aktivno područje | 698.4×392.85 mm |
| obris | 760×450 mm |
| površinski | Antiglare (Haze 5.5%), Hard coating (2H) |
| svjetlina | 430 cd/m² (Typ.) |
| omjer kontrasta | 5000:1 (Typ.) |
| boje prikaza | 1.07B (8-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | 12/8 (Typ.)(Tr/Td); 8 (Typ.)(MPRT) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4 pcsCCFLEmbedded (Inverter) |
| signalno sučelje | LVDS (2 ch, 10-bit), 51 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
| LTA320AN01-C | Samsung | 31.5 | 1366×768 |
| LTA320AP05 | Samsung | 31.5 | 1366×768 |
| LTA320AP16 | Samsung | 31.5 | 1366×768 |
| LTA320AP18 | Samsung | 31.5 | 1366×768 |
| LTA320AP21 | Samsung | 31.5 | 1366×768 |
| LTA320HJ03 | Samsung | 31.5 | 1920×1080 |
| LTA320HN03-W | Samsung | 31.5 | 1920×1080 |
| LTA320W1-L02 | Samsung | 31.5 | 1280×768 |
| LTA320W2-L03 | Samsung | 31.5 | 1366×768 |
| LTA320WT-LF1 | Samsung | 31.5 | 1366×768 |
| LC150V01-SLA1 | LG Display | 15.0 | 640×480 |
| LC320EXJ-SEK1 | LG Display | 31.5 | 1366×768 |
| LC420EUF-SDA1 | LG Display | 42 | 1920×1080 |
| LC420EUH-PEF1 | LG Display | 42 | 1920×1080 |
| LC420WUE-SCV1 | LG Display | 42 | 1920×1080 |
| LC470EUD-SEF2 | LG Display | 47 | 1920×1080 |
| LC470EUE-SDV1 | LG Display | 47 | 1920×1080 |
| LC550EQD-FGF4 | LG Display | 55 | 3840×2160 |
| LC550EUD-SCA2 | LG Display | 55 | 1920×1080 |
| V315B5-L03 | Innolux | 31.5 | 1366×768 |
