| Broj dijela | LTA320AN12 |
| Marka | Samsung |
| Veličina | 31.5 |
| Primjena | LCTV |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 320 |
| CR | 4000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTA320AN12 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 31.5 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | PVA, Normally Black, Transmissive |
| aktivno područje | 697.685×392.256 mm |
| obris | 734.4×430.3 mm |
| površinski | Antiglare, Hard coating |
| svjetlina | 320 cd/m² (Typ.) |
| omjer kontrasta | 4000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193170% |
| vrijeme odziva | 20 (Typ.)(G to G) |
| kut gledanja | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | LVDS (1 ch, 8-bit), 30 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
| LTA320AP05 | Samsung | 31.5 | 1366×768 |
| LTA320AP13 | Samsung | 31.5 | 1366×768 |
| LTA320AP21 | Samsung | 31.5 | 1366×768 |
| LTA320AP29-W | Samsung | 31.5 | 1366×768 |
| LTA320HA04 | Samsung | 31.5 | 1920×1080 |
| LTA320HJ02 | Samsung | 31.5 | 1920×1080 |
| LTA320HN04-W | Samsung | 31.5 | 1920×1080 |
| LTA320W2-L03 | Samsung | 31.5 | 1366×768 |
| LTA320WT-L08 | Samsung | 31.5 | 1366×768 |
| LTA320WT-LF1 | Samsung | 31.5 | 1366×768 |
| HT260WXC-100 | BOE | 26.0 | 1366×768 |
| HV320WHB-N06 | BOE | 31.5 | 1366×768 |
| LC320EXJ-SEK1 | LG Display | 31.5 | 1366×768 |
| LC320WXE-SBV2 | LG Display | 31.5 | 1366×768 |
| LC420WUE-SCV1 | LG Display | 42 | 1920×1080 |
| LC470EUN-SEM1 | LG Display | 47 | 1920×1080 |
| LTY320HN03 | Samsung | 31.5 | 1920×1080 |
| LTY400HA01 | Samsung | 40 | 1920×1080 |
| ST3151A05-5 | CSOT | 31.5 | 1366×768 |
| T260XW03 V3 | AUO | 26.0 | 1366×768 |
