| Broj dijela | LTA230AN01 |
| Marka | Samsung |
| Veličina | 23.0 |
| Primjena | LCTV |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 4000:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | SAMSUNG |
| panelni model | LTA230AN01 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 23.0 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | PVA, Normally Black, Transmissive |
| aktivno područje | 508.152×285.696 mm |
| obris | 534×311.8×11 mm |
| površinski | Antiglare (Haze 2.3%) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 4000:1 (Typ.) |
| boje prikaza | 16.7M (8-bit), CIE193168% |
| vrijeme odziva | 8 (Typ.)(G to G) |
| kut gledanja | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 10S3PWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 8-bit), 30 pins |
| ulazni napon | 12.0V (Typ.) |
| primjena | LCTV |
