| Broj dijela | LR430RC9601 |
| Marka | Innolux |
| Veličina | 4.3 |
| Primjena | PND |
| Rezolucija | 480×272 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 550:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | ChiHsin |
| panelni model | LR430RC9601 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 4.3 inch |
| rezolucija | 480(RGB)×272 , WQVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 95.04×53.856 mm |
| obris | 105.5×67.2 mm |
| površinski | Antiglare |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 550:1 (Typ.) |
| boje prikaza | 16.7M |
| vrijeme odziva | 15/15 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/55/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 10S1PWLEDWithout Driver |
| signalno sučelje | Parallel RGB (1 ch, 8-bit), 45 pins |
| ulazni napon | 3.3V (Typ.)(VCC) |
| primjena | PND |
