| Broj dijela | LQ150X1DWF1 |
| Marka | SHARP |
| Veličina | 15.0 |
| Primjena | DMPC |
| Rezolucija | 1024×768 |
| Sastav | LCM |
| Svjetlina | 250 |
| CR | 400:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | SHARP |
| panelni model | LQ150X1DWF1 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.0 inch |
| rezolucija | 1024(RGB)×768 , XGA |
| način prikaza | MVA, Normally Black, Transmissive |
| aktivno područje | 304.128×228.096 mm |
| obris | 347.3×263.5×16.8 mm |
| površinski | Antiglare (Haze 25%), Hard coating (2H) |
| svjetlina | 250 cd/m² (Typ.) |
| omjer kontrasta | 400:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 15/10 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 4 pcsCCFLWithout Driver |
| signalno sučelje | CMOS/TTL (2 ch, 6-bit), 60 pins |
| ulazni napon | 5.0V (Typ.)(VCC) |
| primjena | DMPC |
