| Broj dijela | LQ104V1LG92 |
| Marka | SHARP |
| Veličina | 10.4 |
| Primjena | GM |
| Rezolucija | 640×480 |
| Sastav | LCM |
| Svjetlina | 330 |
| CR | |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | LVDS |
| marka panela | SHARP |
| panelni model | LQ104V1LG92 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.4 inch |
| rezolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 211.2×158.4 mm |
| obris | 240×179.2 mm |
| površinski | |
| svjetlina | 330 cd/m² (Typ.) |
| omjer kontrasta | |
| boje prikaza | 16.7M (6-bit + Hi-FRC), CIE193172% |
| vrijeme odziva | |
| kut gledanja | |
| frekvencija | 60Hz |
| tip svjetiljke | 2 pcsCCFL |
| signalno sučelje | LVDS (1 ch, 8-bit) |
| primjena | GM |
| LQ104S1DG21 | SHARP | 10.4 | 800×600 |
| LQ104S1DG2A | SHARP | 10.4 | 800×600 |
| LQ104S1DG31 | SHARP | 10.4 | 800×600 |
| LQ104S1LG61 | SHARP | 10.4 | 800×600 |
| LQ104S1LG81 | SHARP | 10.4 | 800×600 |
| LQ104V1DG21 | SHARP | 10.4 | 640×480 |
| LQ104V1DG5A | SHARP | 10.4 | 640×480 |
| LQ104V1DG83 | SHARP | 10.4 | 640×480 |
| LQ104V1LG92 | SHARP | 10.4 | 640×480 |
| LQ104X2LX05A | SHARP | 10.4 | 1024×768 |
| G104X1-L02 | Innolux | 10.4 | 1024×768 |
| G230HAN01.1 | AUO | 23.0 | 1920×1080 |
| LM215WF3-SLK1 | LG Display | 21.5 | 1920×1080 |
| LQ110Y3DG01 | SHARP | 11.0 | 800×480 |
| LQ121S1LG73 | SHARP | 12.1 | 800×600 |
| LQ121S1LG75 | SHARP | 12.1 | 800×600 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| LQ190E1LC06 | SHARP | 19.0 | 1280×1024 |
| LQ6BN01 | SHARP | 5.6 | 320×240 |
| LTA170D200F | TOSHIBA | 17.0 | 1280×1024 |
