| Broj dijela | LQ057AC111 |
| Marka | Other |
| Veličina | 5.7 |
| Primjena | IA |
| Rezolucija | 320×240 |
| Sastav | LCM |
| Svjetlina | 350 |
| CR | 200:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | Parallel/Serial |
| marka panela | CHILIN |
| panelni model | LQ057AC111 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.7 inch |
| rezolucija | 320(RGB)×240 , QVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 115.2×86.4 mm |
| obris | 126×101.55 mm |
| površinski | Antiglare |
| svjetlina | 350 cd/m² (Typ.) |
| omjer kontrasta | 200:1 (Typ.) |
| boje prikaza | 16.7M |
| vrijeme odziva | 15/35 (Typ.)(Tr/Td) |
| kut gledanja | 65/65/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 3S7PWLEDWithout Driver |
| signalno sučelje | Digital RGB (8/24-bit), CCIR601/656, 50 pins |
| ulazni napon | 3.3/5.0V (Typ.)(VDD/AVDD) |
| primjena | IA |
