| Broj dijela | LP156WH8-TLA2 |
| Marka | LG Display |
| Veličina | 15.6 |
| Primjena | NBPC |
| Rezolucija | 1366×768 |
| Sastav | LCM |
| Svjetlina | |
| CR | |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | LG Display |
| panelni model | LP156WH8-TLA2 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.6 inch |
| rezolucija | 1366(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 344.232×193.536 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | |
| svjetlina | |
| omjer kontrasta | |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | |
| kut gledanja | |
| frekvencija | 60Hz |
| tip svjetiljke | WLED |
| signalno sučelje | LVDS (1 ch, 6-bit) |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| LP156WD1-TLD3 | LG Display | 15.6 | 1600×900 |
| LP156WF1-TLE1 | LG Display | 15.6 | 1920×1080 |
| LP156WF1-TPB1 | LG Display | 15.6 | 1920×1080 |
| LP156WF3-SLB3 | LG Display | 15.6 | 1920×1080 |
| LP156WF6-SPB1 | LG Display | 15.6 | 1920×1080 |
| LP156WH2-TLB1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLD1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLF1 | LG Display | 15.6 | 1366×768 |
| LP156WH3-TLL1 | LG Display | 15.6 | 1366×768 |
| LP156WH4-TLA1 | LG Display | 15.6 | 1366×768 |
| LP171WE3-TLA2 | LG Display | 17.1 | 1680×1050 |
| LP171WP4-TLQ1 | LG Display | 17.1 | 1440×900 |
| LTN140AT02-C02 | Samsung | 14.0 | 1366×768 |
| LTN154X3-L02 | Samsung | 15.4 | 1280×800 |
| LTN156AT05-B01 | Samsung | 15.6 | 1366×768 |
| LTN156AT06-001 | Samsung | 15.6 | 1366×768 |
| LTN170BT10-001 | Samsung | 17.0 | 1440×900 |
| N121IB-L06 | Innolux | 12.1 | 1280×800 |
| N133HSE-EA1 | Innolux | 13.3 | 1920×1080 |
| N141C1-L05 | Innolux | 14.1 | 1440×900 |
