| Broj dijela | LP154WX7-TLB3 |
| Marka | LG Display |
| Veličina | 15.4 |
| Primjena | NBPC |
| Rezolucija | 1280×800 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 500:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | LVDS |
| marka panela | LG Display |
| panelni model | LP154WX7-TLB3 1 Compatible model |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 15.4 inch |
| rezolucija | 1280(RGB)×800 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 331.2×207 mm |
| obris | 344×222×6.5 mm |
| stil oblika | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površinski | Glare (Haze 0%) |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 500:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 16 (Typ.)(Tr+Td) |
| kut gledanja | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 6 stringsWLEDWithout Driver |
| signalno sučelje | LVDS (1 ch, 6-bit), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| LP154W01-A3 | LG Display | 15.4 | 1280×800 |
| LP154W02-B1K2 | LG Display | 15.4 | 1680×1050 |
| LP154W02-TL06 | LG Display | 15.4 | 1680×1050 |
| LP154WE2-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP154WE3-TLA2 | LG Display | 15.4 | 1680×1050 |
| LP154WP4-TLB1 | LG Display | 15.4 | 1440×900 |
| LP154WX4-TLA1 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLA3 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLB1 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLP2 | LG Display | 15.4 | 1280×800 |
| B101EW02 V1 | AUO | 10.1 | 1280×720 |
| B154EW01 VC | AUO | 15.4 | 1280×800 |
| B154EW03 V1 | AUO | 15.4 | 1280×800 |
| LP171WU6-TLA2 | LG Display | 17.1 | 1920×1200 |
| LQ121S1LH03 | SHARP | 12.1 | 800×600 |
| LTN121W4-L01 | Samsung | 12.1 | 1280×800 |
| LTN140KT13-B01 | Samsung | 14.0 | 1600×900 |
| LTN154X3-L06-J | Samsung | 15.4 | 1280×800 |
| N140BGE-L22 | Innolux | 14.0 | 1366×768 |
| N140BGE-L42 | Innolux | 14.0 | 1366×768 |
