| Broj dijela | LP125WF2-SPB1 |
| Marka | LG Display |
| Veličina | 12.5 |
| Primjena | NBPC |
| Rezolucija | 1920×1080 |
| Sastav | LCM |
| Svjetlina | 400 |
| CR | 700:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | eDP |
| marka panela | LG Display |
| panelni model | LP125WF2-SPB1 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 12.5 inch |
| rezolucija | 1920(RGB)×1080 , FHD |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno područje | 276.48×155.52 mm |
| obris | 290.5×170.7×2.85 mm |
| stil oblika | Slim (PCBA Flat, Depth ≤3.2mm) |
| površinski | Antiglare |
| svjetlina | 400 cd/m² (Typ.) |
| omjer kontrasta | 700:1 (Typ.) |
| boje prikaza | 262K (6-bit), CIE193150% |
| vrijeme odziva | 35 (Typ.)(Tr+Td) |
| kut gledanja | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLEDEmbedded (LED Driver) |
| signalno sučelje | eDP (2 Lanes), 30 pins |
| ulazni napon | 3.3V (Typ.) |
| primjena | NBPC |
| LP125WF1-SPA2 | LG Display | 12.5 | 1920×1080 |
| LP125WF1-SPD1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLT2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLFA | LG Display | 12.5 | 1366×768 |
| B150XG01 V2 | AUO | 15.0 | 1024×768 |
| B156HW02 V1 | AUO | 15.6 | 1920×1080 |
| HV133WX1-100 | HYDIS | 13.3 | 1280×800 |
| LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
| LP154WX4-TLC8 | LG Display | 15.4 | 1280×800 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LTN133AT25-T01 | Samsung | 13.3 | 1366×768 |
| LTN140KT06-T01 | Samsung | 14.0 | 1600×900 |
| LTN160AT01-W01 | Samsung | 16.0 | 1366×768 |
| LTN160AT02-H02 | Samsung | 16.0 | 1366×768 |
