| Broj dijela | LP104V2-W |
| Marka | LG Display |
| Veličina | 10.4 |
| Primjena | NBPC |
| Rezolucija | 640×480 |
| Sastav | LCM |
| Svjetlina | 200 |
| CR | 150:1 |
| Boje | 262K |
| Pozadinsko osvjetljenje | CCFL |
| Sučelje | TTL |
| marka panela | LG.Philips LCD |
| panelni model | LP104V2-W |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 10.4 inch |
| rezolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno područje | 211.2×158.4 mm |
| obris | 246.5×179.4 mm |
| površinski | Antiglare, Hard coating (3H) |
| svjetlina | 200 cd/m² (Typ.) |
| omjer kontrasta | 150:1 (Typ.) |
| boje prikaza | 262K (6-bit) |
| vrijeme odziva | 30/50 (Typ.)(Tr/Td) |
| kut gledanja | 70/70/45/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | 1 pcsCCFLWithout Driver |
| signalno sučelje | TTL (1 ch, 6-bit), 31 pins |
| ulazni napon | 3.3V (Typ.)(VDD) |
| primjena | NBPC |
