| Broj dijela | LMS500HF13-003 |
| Marka | Samsung |
| Veličina | 5.0 |
| Primjena | PND |
| Rezolucija | 480×272 |
| Sastav | LCM |
| Svjetlina | |
| CR | 800:1 |
| Boje | 16.7M |
| Pozadinsko osvjetljenje | WLED |
| Sučelje | TTL |
| marka panela | SAMSUNG SMD |
| panelni model | LMS500HF13-003 |
| vrsta panela | a-Si TFT-LCD , LCM |
| veličina ploče | 5.0 inch |
| rezolucija | 480×272(RGB) , WQVGA |
| način prikaza | VA, Normally Black, TMR |
| aktivno područje | 110.88×62.832 mm |
| površinski | |
| svjetlina | |
| omjer kontrasta | 800 : 1 (Typ.) |
| boje prikaza | 16.7M (8-bit) |
| vrijeme odziva | 17/15 (Typ.)(Tr/Td) |
| kut gledanja | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvencija | 60Hz |
| tip svjetiljke | WLED |
| signalno sučelje | Parallel RGB (1 ch, 8-bit) |
| ulazni napon | 3.3V (Typ.) |
| primjena | PND |
